심천 Shichuangxinke 전자공학 Co., 주식 회사
전문가는 좋은 품질을 만들고, 각 고객에게 완벽한 제품 및 서비스를 제공합니다.
 |
| 원래 장소: | 중국 |
| 브랜드 이름: | SCXK |
| 인증: | CE/ROHS/FCC/ISO/UL |
| 모델 번호: | P3 |
| 최소 주문 수량: | 10 sqm |
|---|---|
| 가격: | negotiation |
| 포장 세부 사항: | 나무로 되는 케이스 또는 비행 케이스는 유효합니다. |
| 배달 시간: | 7-15 작업 일 |
| 지불 조건: | 전신환, 웨스턴 유니온, 머니그램 |
| 공급 능력: | 한달에 5000sqm |
| 형태를 몰기: | 1/16의 검사 | 실제 화면 크기: | 576x576mm |
|---|---|---|---|
| 애플리케이션 :: | 실내 | 단위 크기:: | 192*192mm |
| 단위 해결책:: | 64*64 화소 | 일 전압:: | AC100-240V |
| 재생율을:: | 3840Hz | 이름: | p3 실내 패널 비디오 월 디지털 신호와 디스플레이 led 화면 |
| 하이 라이트: | SMD2121 배우는 배경 디스플레이를 이끌었습니다,800W 배우는 배경 디스플레이를 이끌었습니다,192*192mm은 무대 비디오 월을 이끌었습니다 |
||
SCX LED full color advertising flexible indoor P3 led billboard video wall screen display panels
| Unit Module Specifications | |
| Item | P3 |
| Pixel Pitch | 3 mm |
| Pixel Configuration | 3in1 (1R1PG1B) |
| Module Size(MM) | 192*192 |
| Module Resolution(Dots) | 64*64 |
| Module Weight(Kg) | 0.3 |
| Package LED Mode | SMD2121 |
| Max Power(Watt) | 21 |
| Pixel Density(Dots/SQM) | 111'111 |
| Driving Method | Constant Current Driving |
| Scan Method(Scan) | 1/32 |
| Interface Way | HUB 75 |
| Brightness(CD/SQM) | ≥ 1500 |
| Safety Standard | CCC,FCC,ROHS,TUV,CE,ETL,UL,BIS..... |
| Unit Cabinet Specifications | |
| Cabinet Size(MM) | 576*576 |
| Cabinet Composing(PCS) | 9 |
| Power Supply Mode(Per Cabinet) | 5V60A |
| Cabinet Resolution(Dots) | 192*192 |
| Optimal Viewing Distance(M) | 3-300 |
| Optimal Viewing Angle | Horizontal angle: 160 degree; Vertical angle: 140 degree |
| Environment Temperature | Storage: -40 degree ~ +85 degree; Work: -20 degree ~ +60 degree |
| Relative Humidity | 10% ~ 95% |
| Power Supply Specifications | |
| Operating Voltage | AC:100V~120V AC:220~240V |
| Average Power(W/SQM) | 150-350 |
| Max Power Consumption(W/SQM) | ≤ 800 |
| Current | ≤ 20mA (single LED) |
| Control System Specifications | |
| Computer | Pentium4 or above P4 or above |
| Operate System | Win7-11/2000/NT/XP |
| Control Mode | Synchronization with PC |
| Main Technical Parameter Specifications | |
| Driving Device | Constant Current Driving |
| Refresh Rate | ≥ 1900-3840Hz |
| Gray/Color | RGB each 256 grade, can display 16.7color |
| Lifespan | ≥ 100000hours |
| Power Switch | RGX Automatic Switch |
| Display Mode | 2048*10241024*7681280*960mm |
| For more information please contact our sales. | |
Die Casting Aluminum Cabinet Details, This Cabinet Is Light, Thin And Is Easy To Intall For
Different Events.
Company profile
Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
our case
Packaging and shipping
Packing:1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
Eachinled has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
