제품 소개투명 한 led 스크린

SMD1921 P3.91 P7.8 투명한 주도하는 광고 커튼 1R1G1B

SMD1921 P3.91 P7.8 투명한 주도하는 광고 커튼 1R1G1B

SMD1921 P3.91 P7.8 Transparent Led Advertising Curtain 1R1G1B
SMD1921 P3.91 P7.8 Transparent Led Advertising Curtain 1R1G1B

제품 상세 정보:

원래 장소: 중국
브랜드 이름: SCXK
인증: CE/ROHS/FCC/ISO/UL
모델 번호: P3.91

결제 및 배송 조건:

최소 주문 수량: 10 sqm
가격: negotiation
포장 세부 사항: 합판 상자, 비행 케이스, 당신은 당신이 좋아하는 무슨을 선택합니다.
배달 시간: 7-15 작업 일
지불 조건: 전신환, 웨스턴 유니온, 머니그램
공급 능력: 한달에 5000sqm
접촉
상세 제품 설명
애플리케이션 :: 투명한, 살아있는 사건에 의하여 지도되는 전시 색: 풀 컬러
패널 사이즈 :: 1000x500mm 화소 피치 :: 3.91 밀리미터
상품 이름 :: 탄력적 투명한 메쉬는 디스플라를 이끌었습니다 핵심어:: 언론 정면 건물을 위한 P 3.91 p4 p5.95screen 벽
모듈 크기 :: 250x250mm 내각 크기:: 1000x500mm
화소 윤곽:: SMD1921 사용: 상업용 광고
증명하세요 :: 세륨 RoHS FCC 수명 :: 100000 시간
하이 라이트:

P7.8 Transparent Led Advertising Curtain

,

SMD1921 Transparent Led Advertising Curtain

,

1R1G1B Indoor LED Glass Panel





Product Description
Item P3.91 High Definition Indoor Glass LED Display for Window
Model Number P3.91
Pixel Pitch 3.9*7.8mm
Pixel Density(dots/m²) 32768
Pixel Configuration 1R1G1B
LED Diode Type SMD3528
Module size(mm) 250*250
Module Resolution(dots) 64*32
Cabinet size(mm) 1000*500
Cabinet resolution 256x64dots
Brightness(cd/m²) 2500
Average Power Consumption(w/m²) 240-800
Scan Mode 1/4
Protection Level IP21
Refresh Rate 1000~1500
Transparent rate >50%
IC MBI5020
Weight 14kg/sqm
Working temperature -10℃~+40℃
Horizontal/Vertical viewing angle

<120°





Features:
1.Ultra-thin & ultra-light
2.Die casted AL cabinets, high precision with seamless splicing
3.Standard cabinet size: 500x500mm, convenient for area calculation
4.Highly effective & quick for transportation and screen assembling
5.SMD black light, wider viewing angle, high-contrast(5000:1),soft image
6.Special buckles structural connection between the cabinets,don’t need other tools
7.Cabinets are in common use for standard modules,shorten production cycle



Parameter:



SMD1921 P3.91 P7.8 투명한 주도하는 광고 커튼 1R1G1B 0

After-Sale Service
1. three year warranty , Lifetime free maintenance.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on
6. Special service for big project, such as stadium, exhibitions, squares and so on.







company profile

SMD1921 P3.91 P7.8 투명한 주도하는 광고 커튼 1R1G1B 1





Certificate
SMD1921 P3.91 P7.8 투명한 주도하는 광고 커튼 1R1G1B 2

Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.


Futures:
1. High transparency effect: The distance between the dots of the transparent led display screen is different, and the light transmittance can be between 50-90%. The perspective effect makes the glass retain the function of the lighting perspective, and the LED lamp can hardly be seen from a distance. The lighting of the glass curtain wall is not affected.

2. Small footprint and light weight: The thickness of the main body of the screen is only 10mm thick. After the LED transparent screen is installed, it takes almost no space and does not hinder other facilities or structures near the glass curtain wall. The LED transparent screen weighs only 14kg/m2, and the load requirements on the glass curtain wall change very little after installation on the glass curtain wall.

3. Only need simple steel frame structure, saving a lot of cost: This product is light in weight, easy to install, does not require complicated supporting steel structure, and can save a lot of installation costs.

4. Easy and fast maintenance: indoor maintenance, which is fast and safe, saves manpower and material resources.

5. Saving the building lighting cost: If the LED transparent screen is installed, it can save a large part of the exterior wall lighting fixtures, and the LED screen is more attractive, which can save costs and have advertising benefits.

6. Energy saving and environmental protection: Its own power consumption is small, and the average power consumption is less than 280W/m2, which does not require traditional cooling system and air conditioning to dissipate heat.

7. Simple operation and strong controllability: It can be connected to the computer, graphics card, remote transceiver through the network cable, or can be replaced at any time by remote cluster wireless control.



FAQ

1. How can i place an order?

Please inform your requirements as clear as possible. So we can send you the offer ASAP.it is better to contact us with Skype/email /phone within project begining, in case of any delays.

2. What kind of display we provide?

We have indoor/outdoor/mobile LED /rental LED display /LED stage/LED Dance Floor/Irregular LED display/stadium LED Display for you choose.

3. What about the lead time for order?

Always: 3-20 days, as your order quantity, sometimes we have stock, can delivery within 5 days

4.How about the warranty ?

2 years warranty.

5. What is your terms of delivery?

We accept EXW, FOB, CFR, CIF, DDU, etc. You can choose the one which is the most convenient or cost effective for you.
