Place of Origin: | China |
브랜드 이름: | SCXK |
인증: | CE,ROHS ,FCC,UL ISO2001 |
Model Number: | SCXK-P2.5 |
Minimum Order Quantity: | 1sqm can be available |
---|---|
가격: | 협상 가능 |
Packaging Details: | the led display can be packaged with wooden box,paper box,flight case |
Delivery Time: | 7-10days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/P, D/A, L/C |
Supply Ability: | 1000sqm/month. we can make the led display on time |
cabinet size: | 640mmx640mm | Display Color: | 16.7million |
---|---|---|---|
Drive Mode: | 1/16 scan | module size: | 160mm x160mm |
Color: | full color | Control system: | synchronization and asynchronization |
module resolution: | 64x64 | cabinet resolution: | 256 x256 |
SMD2121 P2.5 High Defintion Indoor Fixed Led Display RGB 3 Years Warranty
1: the module size :160 x160mm
2: the module resolution :64 x64
3: the cabinet size :480x480mm ,640mm x640mm
4: the cabinet resolution:256x256 384 x384
5. the warranty:3 years warranty. lifeuse :10 years lifeuse
6: the total dots in one square:160000 dots
7: application place: All kinds of in the room.Such as the bus station, subway station.
cinema , supermarket hall
the feature of our product
1. The cabinets, featuring great moisture and corrosion proofing,
enable themselves to work in all weather conditions.
2. Superb refresh rate provides you coherent video effects to
meet your needs for high display quality.
3. Superb cost effective offers you both top notch quality
and reasonable price, maximizing the value of your investment.
The parameter as follow.
The full color Indoor P4 led display parameter as follows. | |||||||||
LED Lamps | Type | SMD2121(High Brightness LEDs) | |||||||
LED Standard | Real Pixel(1R1G1B) | ||||||||
Red Wavelength | 625-630nm | ||||||||
Green Wavelength | 515-530nm | ||||||||
Blue Wavelength | 465-475nm | ||||||||
LED Module | Pixel Pitch | 4mm | |||||||
Module Size | 256mm x128mm | ||||||||
Module Resolution | 64*32dots | ||||||||
LED Cabinet | Cabinet Size | 768mmX768mm | |||||||
Cabinet Resolution | 192pixels *192pixels | ||||||||
Cabinets Material | Sealed Iron Cabinet | ||||||||
LED Display | Pixel Density | 62500pixels/sq.m | |||||||
Drive IC | MBI5024 | ||||||||
Power Supply | Series connection | ||||||||
Brightness | >2500cd/sqm | ||||||||
Display Color | 16.7million | ||||||||
Viewing Angle | 160°(Horizontal),110°(Vertical) | ||||||||
Best Viewing Distance | 4m~200m | ||||||||
Max Power Consumption | 600 w/sq.m | ||||||||
Average Power Consumption | 300 w/sq.m | ||||||||
Weight | 40kgs/sq.m | ||||||||
Refresh Rate | 2000hz | ||||||||
Input Voltage | AC220V/50H or AC110V/60H | ||||||||
Output Voltage | DC5V,40A | ||||||||
Grey Scale Levels | 16bit | ||||||||
Display Colors | R(1024) x G(1024) x B(1024) | ||||||||
MTBF | 10,000 hours | ||||||||
Life-span | 100,000 hours | ||||||||
Protection Level | IP43 | ||||||||
Failure percentage of leds | less than 0.0003 | ||||||||
Working Temperature | -5℃~45℃ | ||||||||
Drive Mode | 1/16 scaning | ||||||||
Working Humidity | 10%~99% |
As the professional manufacturer, we will guarantee every pieces of the led display will be through the strictly test before
shipment. you can benefit from our long time business cooperation. The led display will be packaged well with wooden box.
Products Advantages:
1) Price Advantage: we have the best competitive price at the market; also have the same even better quality;
2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each led lamps;
3) Quality advantage: From material to finished product, from design to produce, we control all steps that are the guarantee of the quality and reliability;
4) Service advantage: Better service at same situation, better cooperation at same service.
Products application area:
the project case for our government
We can provide 24 hours on-line service .No matter what kinds of project do you prefer,just feel free to contact us Then we can give you better solution and service .
