SHENZHEN SHIXIN DISPLAY TECHNOLOGY CO.,LTD

전문성은 좋은 품질을 만들고, 모든 고객에게 완벽한 제품과 서비스를 제공합니다.

제품 소개야외 풀 컬러 Led 디스플레이

SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard

SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard

제품 상세 정보:
원래 장소: 중국의 심천
브랜드 이름: SCXK
인증: CE/ROHS/FCC/ISO/CB
모델 번호: P10
결제 및 배송 조건:
최소 주문 수량: 제한이 없습니다
가격: 협상 가능
포장 세부 사항: 비행 케이스, 목재 케이스, 상자, 그것은 당신에게 달려 있습니다.
배달 시간: 지불을받은 후 7-10 일
지불 조건: T/T, Western Union
공급 능력: 한 달에 5000sqm
접촉
상세 제품 설명
픽셀 피치: 10mm 튜브 칩 컬러: 풀 컬러
LED 유형: SMD 3535 디스플레이 기능: 비디오/텍스트/이미지
캐비닛 재료: 프레임 주파수: > = 60Hz
평균 실패 없음: > = 1000 시간 변환 거리: 인터넷 케이블 <100m
새로 고침 속도: > = 1920Hz 전원 공급 장치: AC80-260V±10%/50Hz,60Hz
강조하다:

SMD IP65 outdoor LED display

,

P10 full color LED billboard

,

building advertising LED screen

SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard
Product Description

SMD IP65 Outdoor Full Color LED Display Screen P8 P10 Building Advertising LED Billboard

The Advantages of P10 Advertising LED Screens
  • Front or rear maintenance option, realizing module, power supply and receiving card front or rear maintenance, saving your maintenance cost.
  • Adopt top high brightness with low power consumption LED lamp, energy-saving ≥30%, if adopt 28 kinds of main patent technique, entire energy-saving ≥50%, environment protection.
  • Free back service path for all kinds of installation surroundings. Broadcast level color scale, color temperature and brightness-adjustable, smooth color, high color ratio, nature pictures.
SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard 0
Technical Parameters of P10 Advertising LED Screens
Parameter Specification
Resolution/mm 10
Pixel configuration 1R1G1B
Pixel density/pixels/m² 10000m2
Module resolution 32*16
Module size/mm 320*160
View distance 10-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >5000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Driving mode Constant driving current
Scanning mode static dring
Frame rate 60Hz
Refresh frequency 3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point <1/10000
Working hours >72hours
Mean time Between Failure >500hours
life time >100000hours
Envirornment temperature range operating temperature range -200c-500c
Maximun power :/m2 <800w
Average power:/m2 <300w
Self-check technolog LEDspot self-check,communication check,power check,temperature monitor(need customization)
Remote monitoring Remote supervision and control,record potential fault send out warning signs to the operators(need customization)
Software environment windows NT,Windows 1999,Windows XP
Input power cable AC110v to220v
Signal input DVI
Warranty 2years quality warranty ,10 years spare parts support
The Feature of P10 Module
  • The use of ultra-high brightness LED and high-quality plastic pieces
  • High-contrast hue can achieve a good display
  • Lightweight, easy to install, remove
  • Can be single-point, single lamp maintenance, low cost
  • Using a constant current way to drive LED, light uniformity, low power consumption
  • The pixel pitch is 6mm, a total of 32 * 16 pixels, each pixel consists of 1R1G1B
The Advantages of our Products
  • The product structure is resistant to 100 Km / h wind and 8 earthquakes.
  • With excellent waterproof performance, safe and reliable power system.
  • All components of the product can be processed according to customer requirements.
  • All materials are environmentally friendly materials.
  • The life of the product is more than 5 years.
  • The warranty is for 2~5 years.
  • We can provide additional installation, permanent technical supports, and training services.
SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard 1 SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard 2 SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard 3 SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard 4
Control System
SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard 5
Certificates
SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard 6
Our Mission

To be the premier provider of creative, marketing and innovative solutions devoted to helping other companies succeed and grow.

Why Choose Us?
SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard 7
Packing & Shipping

Packing: wooden case, flight case for choose

Shipping: by air, sea, train, DHL, you are the boss

SMD IP65 Outdoor Full Color LED Display Screen P10 Building Advertising LED Billboard 8
FAQ
  • How can I place an order?
    Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype/email /Whatsapp, in case of any delays.
  • What kind of display do we provide?
    We have indoor/outdoor/mobile LED /rental LED display /LED stage/ Advertising LED display for you to choose. The customized service also could be provided
  • What about the lead time for an order?
    Always: 7-17 days after receiving your payment, as your order quantity, sometimes we have stock, can delivery within 7 days
  • What about the warranty?
    We have 2~5 years of quality guaranteed, spare parts such as the led module, receiving card, control card, power supply are damaged not cause of artificial damaged, then it's free maintenance and ship back new ones for replacement.
  • How about the quality?
    Our led products must be testing of at least 72hours before shipping, from purchase raw materials to ship, Each step has strict quality control systems to ensure led display with good quality
  • Can you offer technical support? Since it's my first time....
    We provide free training for our customer, teach the client how to set up screens, make configuration of parameters, broadcast the videos through Nova star and colorlight or Linsn control systems, our engineer can directly teach you how to control, or help you to do if you are really don't know how to control(Our Engineer can text English, we can saving more time )
