| 원래 장소: | 중국의 심천 |
| 브랜드 이름: | SCXK |
| 인증: | CE/ROHS/FCC/ISO/CB |
| 모델 번호: | P10 |
| 최소 주문 수량: | 제한이 없습니다 |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 비행 케이스, 목재 케이스, 상자, 그것은 당신에게 달려 있습니다. |
| 배달 시간: | 지불을받은 후 7-10 일 |
| 지불 조건: | T/T, Western Union |
| 공급 능력: | 한 달에 5000sqm |
| 픽셀 피치: | 10mm | 튜브 칩 컬러: | 풀 컬러 |
|---|---|---|---|
| LED 유형: | SMD 3535 | 디스플레이 기능: | 비디오/텍스트/이미지 |
| 캐비닛 재료: | 철 | 프레임 주파수: | > = 60Hz |
| 평균 실패 없음: | > = 1000 시간 | 변환 거리: | 인터넷 케이블 <100m |
| 새로 고침 속도: | > = 1920Hz | 전원 공급 장치: | AC80-260V±10%/50Hz,60Hz |
| 강조하다: | SMD IP65 outdoor LED display,P10 full color LED billboard,building advertising LED screen |
||
SMD IP65 Outdoor Full Color LED Display Screen P8 P10 Building Advertising LED Billboard
| Parameter | Specification |
|---|---|
| Resolution/mm | 10 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 10000m2 |
| Module resolution | 32*16 |
| Module size/mm | 320*160 |
| View distance | 10-300m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >5000cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Driving mode | Constant driving current |
| Scanning mode | static dring |
| Frame rate | 60Hz |
| Refresh frequency | 3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | >72hours |
| Mean time Between Failure | >500hours |
| life time | >100000hours |
| Envirornment temperature range | operating temperature range -200c-500c |
| Maximun power :/m2 | <800w |
| Average power:/m2 | <300w |
| Self-check technolog | LEDspot self-check,communication check,power check,temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control,record potential fault send out warning signs to the operators(need customization) |
| Software environment | windows NT,Windows 1999,Windows XP |
| Input power cable | AC110v to220v |
| Signal input | DVI |
| Warranty | 2years quality warranty ,10 years spare parts support |
To be the premier provider of creative, marketing and innovative solutions devoted to helping other companies succeed and grow.
Packing: wooden case, flight case for choose
Shipping: by air, sea, train, DHL, you are the boss
